| Zones Number | 33 zones |
|---|---|
| Display Type | Touch LED screen |
| Inner Frame | 2000mm(H)x700mm(W)x500mm(D) |
| Power | AC85～264V 50/60Hz |
33 zones
MBSU backup battery(optional)
Mix distance between two Walk-thru:0.3 meters at low sensitivity, 0.5meters at high sensitivity
Harmless to pregnant woman and heart pacemaker
Anti-interference standard: EN50082-1
DSP technology, automatically calibration
Weather-proof design( Aluminum Case) waterproof IP65
LCD display
| Technical specification | |
| Electrical current: | AC80V~250V 50/60Hz |
| Power: | 8W |
| Work environment: | -20℃ to +50℃ |
| Gross Weight: | 54 kgs |
| Outer frame: | 2230mm (h)*930mm (w)*300mm (d) |
| Inner frame: | 2010mm (h) *720mm (w) *300mm (d) |
| Characteristic | |
| Self-diagnostic procedures Support Input MBSU battery backup, in time power transfer Modular structure easy for after sales service Automatically adapt to the working environment Auto scan environmental interference at site LCD friendly operation interface for user Operation way: remote control Two LED light bars on both door panels: gives alarm corresponding to the height or human body. Detect zone: 33 zones Sensitivity adjustable from Level 0 to 300 High: Can detect a clip Low: Detect big metal articles such as: knife, gun, and copper, aluminums, zinc (more than 150g), ignoring metal in belt button, shoes. Shock proof to avoid false alarm Sound and light alarm Intelligent traffic and alarm counters that calculate traffic flow and resultant alarms. Tamper-Proof: operate program is protected by password. Adjustable operating frequencies—eliminate the potential effects from X-ray units, radios and other electrical interference sources. Connect with computer, camera, turnstile(Optional) |
|
One of the largest manufacturers and suppliers of metal detector, X-ray baggage scanners in China, with the widest product line of and EOD security equipment
