| Zones Number | 12 zones, 18 zones, 6 zones |
|---|---|
| Display Type | Nixie tube |
| Inner Frame | 2000mm (h) X 700mm (w) X 400mm (d) |
| Power | AC85～264V 50/60Hz |
* Stable performance, 6-12-18 zones options
*Extremely high sensitivity to find even tiny threats
*Operation way: remote control
*Two LED lights bars show threats location on human body
* Sound and light alarm
Technical specification | |
| Electrical current: | AC85～264V 50/60Hz |
| Power: | 10W |
| Work environment: | -20℃ to +65℃ |
| Gross Weight: | 48 kg |
| Outer frame: | 2230mm (h) x 800mm (w) X 400mm (d) |
| Inner frame: | 2000mm (h) X 700mm (w) X 400mm (d) |
Characteristic | |
| Two LED light bars on both door panels: gives alarm corresponding to the height or human body. | |
| 6/12/18 Pinpoint zones to precisely identify multiple target locations from head to toe. | |
| Advanced broadband detection technology: can detect ferrous and non-ferrous articles. | |
| Sensitivity adjustable from Level 0 to 2048 | |
| High: Can detect a clip | |
| Low: Detect big metal articles such as: knife, gun, and copper, aluminums, zinc (more than 150g), ignoring metal in belt button, shoes. | |
| Shock proof to avoid false alarm | |
| Sound and light alarm | |
| Intelligent traffic and alarm counters that calculate traffic flow and resultant alarms. | |
| Tamper-Proof: operate program is protected by password. | |
| Adjustable operating frequencies—eliminate the potential effects from X-ray units, radios and other electrical interference sources. | |
| Mix distance between two Walk-thru: 0.3 meters at low sensitivity, 0.5 meters at high sensitivity | |
| Harmless to pregnant woman and heart pacemaker | |
| Operation way : Remote control | |
| (Optional)Connect with computer, camera, turnstile, etc | |
One of the largest manufacturers and suppliers of metal detector, X-ray baggage scanners in China, with the widest product line of and EOD security equipment
